Europe Standard Battery Chicken Cage For Poultry Layers And Broilers, Good Ventilation
Introduction Of Battery Chicken Cage For Poultry Layers And Broilers:
Silver Star's European standard battery chicken cage system, known for its larger size, is designed to offer excellent ventilation for chickens.
In the European-sized poultry layers battery chicken cage, each door measures 650mm in length, 625mm in depth, and 440mm in height, holding nine birds per door and providing each bird with 450 square centimeters of space.
In the European-sized poultry broilers battery chicken cage, each door measures 1000mm in length, 1000mm in depth, and 440mm in height, holding twenty birds per door and providing each bird with 500 square centimeters of space.
Advantages Of Battery Chicken Cage For Poultry Layers And Broilers:
1. Constructed with Q235 bridge wire, the poultry layers and broilers battery chicken cage remains robust and resistant to bending over prolonged use.
2. Ensuring proper airflow, the large-sized battery chicken cage systems provide a beneficial breeding environment for layers and broilers chickens.
3. Adopting battery chicken cages for poultry layers and broilers in high-density breeding saves land and investment, making it easier to observe, select, and manage the birds, especially the weaker ones.
4.Through hot-dip galvanized processing, the full set of battery chicken cage equipment achieves corrosion resistance and a lifespan exceeding 25 years.
5.Through hot-dip galvanized processing, the full set of battery chicken cage equipment achieves corrosion resistance and a lifespan exceeding 25 years.
6. Separating chicken manure to fall directly onto the belt greatly reduces dust levels in the chicken house, lowers the risk of disease spread from manure, and significantly decreases bird mortality rates.
7. This system is adaptable for use in both closed and open chicken houses, utilizing automated ventilation and temperature control to effectively mitigate issues caused by hot weather.
8. Implementing the belt cleaning method effectively enhances air quality in the chicken house, thereby reducing the incidence of certain diseases and ensuring optimal safety measures.
9. Maintaining high cleanliness and minimizing egg breakage.
Specification Of European Standard Poultry Layers And Broilers Battery Chicken Cage:
| Type H Poultry Layers Battery Chicken Cage |
| Model | Door No. /cage | Chicken No. /door | No. of layers | Capacity of one set of cage | Area per bird (cm2/bird) | Each door size(mm) | Cage size/set (mm) |
| H3L54 | 1 | 9 | 3 | 54 | 450 | 650x625x440 | 650x1250x2220 |
| H4L72 | 1 | 9 | 4 | 72 | 450 | 650x625x440 | 650x1250x2870 |
| H5L90 | 1 | 9 | 5 | 90 | 450 | 650x625x440 | 650x1250x3520 |
| H6L108 | 1 | 9 | 6 | 108 | 450 | 650x625x440 | 650x1250x4170 |
| H8L144 | 1 | 9 | 8 | 144 | 450 | 650x625x440 | 650x1250x5470 |
| Full equipment | H Frame Battery Chicken Cage For Poultry Layers, Automatic feeding machine, automatic drinking system, automatic egg collection and automatic manure cleaning system, ventilation system |
| Type H Poultry Broilers Battery Chicken Cage |
| Model | Door No. /cage | Chicken No. /door | No. of layers | Capacity of one set of cage | Area per bird (cm2/bird) | Each door size(mm) | Cage size/set (mm) |
| H3B60 | 1 | 20 | 3 | 60 | 500 | 1000x1000x440 | 1000x1000x2200 |
| H4B80 | 1 | 20 | 4 | 80 | 500 | 1000x1000x440 | 1000x1000x2850 |
| H3B90 | 1 | 30 | 3 | 90 | 500 | 1500x1000x440 | 1500x1000x2200 |
| H4B120 | 1 | 30 | 4 | 120 | 500 | 1500x1000x440 | 1500x1000x2850 |
| H3B156 | 4 | 13 | 3 | 156 | 500 | 740X850X440 | 1480X1750X2800 |
| H4B208 | 4 | 13 | 4 | 208 | 500 | 740X850X440 | 1480X1750X3600 |
| Full equipment | H Frame Battery Chicken Cage For Poultry Broilers, Automatic feeding system, automatic drinking system, automatic manure removal system, automatic birds harvesting system, ventilation system |
Why Use Battery Chicken Cage In Poultry Production?
1. Reduce feed waste and improve productivity in layer poultry production.
2. Increased production
3. Optimized management of the flock
4. Minimize labor costs
5. Absence of accidental deaths
6. Optimized poultry waste management
7. These cages can be used again.
